Technical Specification

CA-Q1-D Receiver
Receiving mode：Double tuner automatic signal selection
Frequency range：A: 694.4-702.8MHz
Modulation mod：FM
Oscillation mode：Digital modulation frequency synthesis
Sensitivity：-45Hz-18KHz±3db
Bandwidth：8.4MHz
Comprehensive frequency response：When input is 6dBv, S/N＞60db
Power supply：DC 12V~16V 10w
Output sockets：XLR balanced and 6.3 unbalanced sockets
Operation temperature：10°C-60°C

CA-T49-D  Bodypack
Oscillation : PLL phase locked frequency synthesis Harmonic radiationMore than 50dBm lower than the main wave Maximum deviation ±45KHz
Frequency Band : A: 694.4-702.8MHz
Input Socket : 3.5 mm
RF Output Power : 10/30 mw
Current consumption : 110mA (typical)
Battery consumption : 8 hours
Battery : AA size
Size : 95x63x22
Weight : 79 g

CA-MS Instrument Mic
Saxophones, Trumpets, Drums, Wind Instruments, Congas – Studio, Live Performance
